Biochemical sewage treatment plant (BF SYSTEM)
After undergoing a gravitational transfer treatment process inside the device,
the inflow sewage is filtered through a filter and treated below the MEPC IMO227(64) standard to discharge it out of the ship.
- There is no need to use existing chemicals.
- There is no use of dilute water.
- COMPACT SIZE
- Simple operational and economic maintenance costs
Product information
Product specifications
| Sortation | BF20CE | BF30CE | BF40CE | BF60CE | BF100CE | BF150CE | BF200CE | BF300CE | BF400CE | |
|---|---|---|---|---|---|---|---|---|---|---|
| Person Black Water Based |
20 | 30 | 40 | 60 | 100 | 150 | 200 | 300 | 400 | |
| Capacity[㎘/day] | 1.4 | 2.1 | 2.8 | 4.2 | 7 | 10.5 | 14 | 21 | 28 | |
| Sewage Volume | 70 l/man, day | |||||||||
| Dimention [mm] |
L | 1000 | 1000 | 1000 | 1200 | 1200 | 1400 | 2100 | 2300 | 2600 |
| W | 850 | 900 | 950 | 950 | 1150 | 1250 | 1600 | 1600 | 1600 | |
| H | 1200 | 1250 | 1300 | 1300 | 1400 | 1500 | 1600 | 2000 | 2100 | |
| Sewage Tank [L] | 167 | 175 | 182 | 219 | 237 | 340 | 911 | 1151 | 1453 | |
| Filter Tank [L] | 615 | 701 | 792 | 950 | 1345 | 1887 | 2916 | 4145 | 4845 | |
| Discharge Tank [L] | 92 | 100 | 107 | 129 | 147 | 165 | 454 | 727 | 921 | |
| Weight [kg] | 510 | 530 | 560 | 620 | 700 | 800 | 1150 | 1750 | 1900 | |
| Electric Power | AC220V. AC440V [50Hz/60Hz] | |||||||||
| Model Electric Consume [kw] |
2.0 | 2.0 | 2.0 | 2.0 | 2.5 | 3 | 3 | 3.5 | 3.5 | |
